Ultra II Deck Pipe – Deck Pipe | ID: DN125/4.8″ | OAL: 122.00″ | WT: 6.6mm/.261″ | Hevi-Dutyâ„¢ | HT

$432.90

SKU: B504C200DH Category:

Description

Deck Pipe | ID: DN125/4.8″ | OAL: 122.00″ | WT: 6.6mm/.261″ | Hevi-Dutyâ„¢ | HT Ultra II single wall deck pipe is hardened for longer life. Best paired with cast manganese elbows. and single wall reducers and backend kits.
New boom and deck parts meet or exceed 85 bar working and 170 bar burst pressure ratings, and are tagged with size, part number, weight (FWC) and working pressure.
INSIDE DIAMETER [IN/MM] – DN125/4.8″, END STYLE – Hevi-Duty™, LENGTH [IN/MM] – 122.00″ / 3099mm, HEAT TREATMENT – Heat Treated, WALL THICKNESS [IN/MM] – 0.261″ / 6.6mm, Wall Type – Single Wall, MODEL – Guardian Deck Pipe, Pressure – Meets 85 bar working / 170 bar burst – Yes, PRESSURE RATING [BAR/PSI] – 400 / 5800, Weight – F.W.C. / foot – 33.5 lbs/ft (15.2 kg/ft), Weight – Empty / foot – 14.2 lbs/ft (6.4 kg/ft), Hardness – Up to 57HRc, Typical Application – Deck,
