Laydown/Placing Pipe – Laydown/Placing Pipe | ID: DN127/5″ | WT: 0.25 | OAL: 9ft | End: Hevi-Duty™ | HT

Description

Laydown/Placing Pipe | ID: DN127/5″ | WT: 0.25 | OAL: 9ft | End: Hevi-Duty™ | HT Steel laydown/placing line components comes in multiple wall thicknesses, sizes, and configurations to match a multitude of line-pumping applications. Hardened versions are available for longer life.
Pressure and wear indicator tools are available for professional system monitoring and maintenance programs.
INSIDE DIAMETER [IN/MM] – DN127/5″, END STYLE – Hevi-Duty™, LENGTH [IN/MM] – 108.00″ / 2743mm, HEAT TREATMENT – Heat Treated, WALL THICKNESS [IN/MM] – 0.250″ / 6.35mm, Wall Type – Single Wall, MODEL – Laydown Line, PRESSURE RATING [BAR/PSI] – 375 / 5437, Typical Application – Laydown, CLASSIFICATION – Endurance,
